Lub Hwj Chim Ntiaj Teb lub tank dej kub hauv tsev thiab lub tank tsis tuaj yeem txais cov hlau tsis zoo li lub tank sab hauv, uas tuaj yeem tiv thaiv xeb thiab xeb, muab kev txuag hluav taws xob zoo, kev noj qab haus huv ntau dua thiab kev nyab xeeb, thiab lub neej ua haujlwm ntev.
Khoom Description
Kaw thiab lub siab-txheej txheem tsim, khiav nrog tag nrho cov dej, muab cov dej kub los ntawm lub siab ntawm cov kais dej, lub siab tsis tu ncua, thiab qhov kub thiab txias ntawm qhov hluav taws xob, kom siv tau yooj yim dua.
Nws tuaj yeem txuas nrog cov khoom siv cua sov xws li boilers thiab cov twj tso cua sov kom khaws cov dej kub rau qee zaus.
Nruab nrog qhov chaw nres nkoj dej rov qab, txuas nrog lub tshuab xa dej rov qab, cov dej txias tuaj yeem ua kom sov tam sim ntawd, uas zoo heev thiab txuag dej rau cov neeg siv.
Nruab nrog ib txoj kev nyab xeeb valve thiab tsis zoo siab kev nyab xeeb valve, uas tuaj yeem tiv thaiv kev nyab xeeb ntawm lub tank dej.
Lub zog anode pas nrig yog tus qauv, uas tuaj yeem tiv thaiv corrosion thiab ua kom lub neej ntev ntawm cov dej tank.
Txais kev teeb tsa hauv pem teb, uas yooj yim rau nruab thiab tswj, thiab haum rau ntau qhov chaw.
Specification
| Qauv | PW-150L | PW-200L | PW-200L-1 | PW-250L | PW-300L | PW-300L-1 |
| Tank Volume (L) | 150 | 200 | 200 | 250 | 300 | 300 |
| Inner Tank khoom | SUS 304 | SUS 304 | SUS 304 | SUS 304 | SUS 304 | SUS 304 |
| Sab hauv Tank Thickness (mm) | 1.0 | 1.2 | 1.2 | 1.4 | 1.4 | 1.4 |
| Plhaub Khoom | Xim Phaj | |||||
| Plhaub Thickness (mm) | 0.4 | 0.4 | 0.4 | 0.4 | 0.4 | 0.4 |
| Coil Khoom | SUS 304 | SUS 304 | SUS 304 | SUS 304 | SUS 304 | SUS 304 |
| Coil Hom | Corrugated yeeb nkab | Corrugated yeeb nkab | Corrugated yeeb nkab | Ordinary Pipe | Corrugated yeeb nkab | Corrugated yeeb nkab |
| Coil Specifications (hli) | φ25 hli * 15m | φ25 hli * 20m | φ25 hli * 20m | φ22 hli * 22m | φ25 hli * 20m | φ25mm * 30m |
| Coil Thickness (hli) | 0.3 | 0.3 | 0.3 | 1.0 | 0.3 | 0.3 |
| Cheeb tsam (㎡) | 1.6 | 2.2 | 2.2 | 1.5 | 2.2 | 3.3 |
| Dej txias Inlet | G3/4" M | |||||
| Lub qhov dej kub | G3/4" M | |||||
| Circulating Dej Inlet | G1" M | G1" M | G1" M | G3/4" M | G1" M | G1" M |
| Circulating Water Onlet | G1" M | G1" M | G1" M | G3/4" M | G1" M | G1" M |
| Rov qab dej | G3/4" M | G3/4" F | G3/4" F | G3/4" M | G3/4" M | G3/4" F |
| Hluav taws xob rhaub Chaw nres nkoj | / | / | G1" F | / | / | G1" F |
| Electric rhaub (KW) | / | / | 3 kW | / | / | 3 kW |
| Temperature Detection Port | G1/4" F | |||||
| Anode Qws | G3/4" F | |||||
| P/T Valve Chaw nres nkoj | / | G3/4" F | / | G3/4" F | ||
| Chaw nres nkoj dej phwj tuaj | G3/4" M | |||||
| Ua Haujlwm Siab Bar | 8 | 8 | 8 | 8 | 8 | 8 |
| Rwb thaiv tsev txheej | Polyurethane | |||||
| Rwb thaiv tsev Thickness (mm) | 50 | 45 | ||||
| Khoom Loj (mm) | φ470*1525 | φ520*1575 | φ520*1575 | φ560*1605 | φ560*1885 | φ560*1885 |
| Pob Loj (mm) | 540*540*1530 | 595*595*1590 | 595*595*1590 | 630*630*1670 | 630*630*1950 | 630*630*1950 |
Cim npe nrov: domestic dej kub tank
